Intel® Core™ i5-9400 Processor 9th Gen

Essentials

• Lithography: 14 nm
• Sockets Supported: FCLGA1151
• Max CPU Configuration: 1
• Thermal Solution Specification: PCG 2015C (65W)
• Embedded Options Available: No

Performance

• # of Cores: 6
• # of Threads: 6
• Processor Base Frequency: 2.90 GHz
• Max Turbo Frequency: 4.10 GHz
• Cache: 9 MB SmartCache
• Bus Speed: 8 GT/s DMI3
• TDP: 65 W

Memory Specifications

• Max Memory Size (dependent on memory type): 64 GB
• Memory Types: DDR4-2666
• Max # of Memory Channels: 2
• Max Memory Bandwidth: 41.6 GB/s
• ECC Memory Supported: No

Graphics Specifications

• Processor Graphics: Intel® UHD Graphics 630
• Graphics Base Frequency: 350 MHz
• Graphics Max Dynamic Frequency: 1.05 GHz
• Graphics Video Max Memory: 64 GB
• 4K Support: Yes, at 60Hz
• Max Resolution (HDMI 1.4): 4096 x 2304@24Hz
• Max Resolution (DP): 4096 x 2304@60Hz
• Max Resolution (eDP - Integrated Flat Panel): 4096 x 2304@60Hz
• DirectX* Support: 12
• OpenGL* Support: 4.5
• Intel® Quick Sync Video: Yes
• Intel® InTru™ 3D Technology: Yes
• Intel® Clear Video HD Technology: Yes
• Intel® Clear Video Technology: Yes
• # of Displays Supported: 3
• Device ID: 0X3E98/x92

Expansion Options

• Scalability: 1S Only
• PCI Express Revision: 3.0
• PCI Express Configurations: Up to 1x16, 2x8, 1x8+2x4
• Max # of PCI Express Lanes: 16

Advanced Technologies

• Intel® Optane™ Memory Supported: Yes
• Intel® Turbo Boost Technology: 2.0
• Intel® vPro™ Platform Eligibility: No
• Intel® Hyper-Threading Technology: No
• Intel® Virtualization Technology (VT-x): Yes
• Intel® Virtualization Technology for Directed I/O (VT-d): Yes
• Intel® VT-x with Extended Page Tables (EPT): Yes
• Intel® TSX-NI: No
• Intel® 64: Yes
• Instruction Set: 64-bit
• Instruction Set Extensions: Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2
• Idle States: Yes
• Enhanced Intel SpeedStep® Technology: Yes
• Thermal Monitoring Technologies: Yes
• Intel® Identity Protection Technology: Yes
• Intel® Stable Image Platform Program (SIPP): No

Security & Reliability

• Intel® AES New Instructions: Yes
• Secure Key: Yes
• Intel® Software Guard Extensions (Intel® SGX): Yes with Intel® ME
• Intel® Memory Protection Extensions (Intel® MPX): Yes
• Intel® OS Guard: Yes
• Intel® Trusted Execution Technology: No
• Execute Disable Bit: Yes
• Intel® Boot Guard: Yes
