Asrock J3355B-ITX
Product Type:
Motherboards
Type Detail:
Intel Socket 478
Manufacturer:
ASRock America
Manufacturer #:
J3355B-ITX
Part Status:
Phase-Out
Milwaukee PC SKU:
264290
Price:
$99.99

Quick Tech Specs

Processor Manufacture: Intel
Brand: ASRock
SLI Support: NONE
Crossfire Support: NONE
Number of Memory Slots: 2 Slots
Max Memory: 16GB
Memory Type: DDR3
PCI Express x16 Slots: 1 Slots
PCI Express x1 Slots: None
PCI Slots: None
WiFi Onboard: NONE
RAID Support: NONE
Sata 6 Gbits/s Ports (3.0/3.1): None
Sata 3 Gbits/s Ports (2.0): 2 Ports
Sata Express 16 Gbits/s Ports (3.2): None
M.2 Slots: None
NVMe Support: No
eSata Ports: None
Legacy Ports: 1 Serial Port & 1 Parallel Port
Thunderbolt Ports: NONE
Network Ports: Gigabit (10/100/1000)
Display Ports: NONE
DVI Ports: NONE
HDMI Ports: 1 Ports


Asrock J3355B-ITX


Form Factor

  • Mini-ITX Form Factor: 6.7-in x 6.7-in, 17.0 cm x 17.0 cm - Solid Capacitor design

CPU

  • Intel® Dual-Core Processor J3355 (up to 2.5 GHz)

Memory

  • Dual Channel DDR3/DDR3L Memory Technology, - 2 x DDR3/DDR3L SO-DIMM Slots, - Supports DDR3/DDR3L 1866/1600/1333 non-ECC, un-buffered memory, - Max. capacity of system memory: 16GB

Graphics

  • Integrated Intel® HD Graphics 500: 12 EUs inside (Up to 700MHz) - DirectX 12, Pixel Shader 5.0 - Dual graphics output: support D-Sub and HDMI ports by independent display controllers - Supports HDMI with max. resolution up to 4K x 2K (3840x2160) @ 30Hz or 2560x1600 @ 60Hz - Supports D-Sub with max. resolution up to 1920x1200 @ 60Hz - Supports Auto Lip Sync, xvYCC and HBR (High Bit Rate Audio) with HDMI Port (Compliant HDMI monitor is required) - Supports HW Accelerated Decoders: H.264 @ level 5.2, HEVC (H.265) 10b @MP level 5.1 (GPU accelerated), JPEG, VP8, VP9 - Supports HDCP with HDMI Port - Supports Full HD 1080p Blu-ray (BD) playback with HDMI Port

Expansion Slots

  • 1 x PCI Express 2.0 x16 Slot (PCIE1: x2 mode)

Storage

  • 2 x SATA3 6.0 Gb/s Connectors, support NCQ, AHCI and Hot Plug

LAN

  • PCIE x1 Gigabit LAN 10/100/1000 Mb/s - Realtek RTL8111GR - Supports Wake-On-WAN - Supports Wake-On-LAN - Supports Lightning/ESD Protection (ASRock Full Spike Protection) - Supports LAN Cable Detection - Supports Energy Efficient Ethernet 802.3az - Supports PXE

Audio

  • 7.1 CH HD Audio (Realtek ALC887 Audio Codec)* - Supports Surge Protection (ASRock Full Spike Protection) - ELNA Audio Caps

OS Support

  • Microsoft® Windows® 10 64-bit, - Linux: Ubuntu 16.10 / Fedora 25

Internal I/O Ports

  • 1 x COM Port Header - 1 x Chassis Intrusion Header - 1 x TPM Header - 1 x CPU Fan Connector (3-pin) - 1 x Chassis Fan Connector (3-pin) - 1 x 24 pin ATX Power Connector - 1 x Front Panel Audio Connector - 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD Protection (ASRock Full Spike Protection)) - 1 x USB 3.1 Gen1 Header (Supports 2 USB 3.1 Gen1 ports) (Supports ESD Protection (ASRock Full Spike Protection))

Back I/O Ports

  • 1 x PS/2 Mouse Port - 1 x PS/2 Keyboard Port - 1 x Parallel Port (ECP/EPP Support) - 1 x Serial Port: COM1 - 1 x D-Sub Port - 1 x HDMI Port - 1 x USB 2.0 Port (Supports ESD Protection (ASRock Full Spike Protection)) - 3 x USB 3.1 Gen1 Ports (Supports ESD Protection (ASRock Full Spike Protection)) - 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED) - HD Audio Jacks: Line in / Front Speaker / Microphone

H/W Monitoring

  • CPU, Chassis temperature sensing - CPU, Chassis Fan Tachometer - CPU, Chassis Quiet Fan (Auto adjust chassis fan speed by CPU temperature) - CPU, Chassis Fan multi-speed control - Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore

Accessories

  • Quick Installation Guide, Support CD, I/O Shield - 2 x SATA Data Cables

Bundled Software

  • Software - ASRock Power Gear - ASRock XFast LAN* UEFI - ASRock Power Gear - ASRock Instant Flash - ASRock Internet Flash - ASRock Crashless BIOS
