ASUS Prime AP201
The ASUS Prime AP201 Tempered Glass Version is a breakthrough in microATX chassis design, delivering a high-performance platform that invites 360 mm AIO coolers and graphics cards up to 338 mm long, all within a compact 33-liter space. Tool-free side panels also provide easy access, and they complete a tasteful, minimalist aesthetic that can be the centerpiece of any DIY PC build.
With support for 280 and 360mm radiators and up to 6 fans, the AP201 is primed to deal with the thermal onslaught of convention-defying SFF rigs loaded with multi-core CPUs and high-end graphics cards.
The two 120 mm fan mounts at the bottom of the AP201 include a dust filter that can be removed for easy cleaning, or to enhance airflow even further.
Instead of making you wrestle with screws or potentially awkward hinges, the side panels of the AP201 both use a simple but secure clip mechanism to attach to the case. This makes them easy to remove when you want to access the interior of the chassis, and resistant to being accidentally dislodged.
Highlights
- Case Size: Small Tower
- Motherboard Support: Micro-ATX, Mini-ITX
- Expansion Slots: 4
- Drive Bays: 1 x 2.5" Bay, 3 x 2.5"/3.5" Combo Bay
- Front I/O Port:
1 x Headphone,
1 x Microphone,
2 x USB 3.2 Gen1,
1 x USB 3.2 Gen2 Type C
- Pre-installed Fans (Rear): 1 x 120 mm
- Radiator Support (Top):
120 mm,
140 mm,
240 mm,
280 mm,
360 mm
- Radiator Support (Rear): 120 mm
- Fan Support: Top - 3 x 120 mm, 2 x 140 mm, Rear - 1 x 120 mm
- Maximum CPU Cooler Height: 170 mm
- Maximum GPU Length: 338 mm
- Maximum PSU Length: 140-180 mm
- Removable Dust Filters: Bottom
- Maximum Cable Management Space: 32 mm
