Phanteks NV7 Black - Full ATX, no PS, RGB, 2 Side TG

Product Type:

Cases

Type Detail:

Full ATX

Manufacturer:

UnListed

Manufacturer #:

PH-NV723TG_DBK01

Part Status:

Special Order Only

Milwaukee PC SKU:

57666

Price:

$269.99

Quick Tech Specs

Form Factor:	ATX
Type:	Full Tower
Brand:	Phanteks
P.Supply Incl.:	NONE
P.Supply Location:	Bottom
P.Supply Wattage:	NONE
Expantion Slots:	8 Slots
External 2.5" Bays:	NONE
External 5.25" Bays:	NONE
External 3.5" Bays:	NONE
Internal 3.5" Bays:	1 Bay
Internal 2.5" Bays:	6 Bays
Front USB-C:	1-Port
Front USB 3.+ Ports:	2 Ports
Material:	Steel
Window:	YES / Side + Front
Warranty:	5 Years

Phanteks NV7

The Phanteks NV7, with its unmistakable purpose design, highlights the system components with the motherboard at its center. One defining design element of the NV7 is its strong and defining outer frame that captures and accentuates the hardware components.

With a clean design from all sides, the NV7 allows you to place your system freely without the traditionally messy rear side. The glass panels offer a near-seamless view of the inside to further focus on the system components.

Creating a picture-perfect build is the core element of the NV7, with fans positioned all around the motherboard, the heart of your system, like a picture frame. The near-seamless glass panels provide a perfect view of all your system components.

Integrated fan/radiator brackets, LED cable covers, airflow covers, and an array of unique cable management tools make any NV7 build stand out from the crowd.

The ultra-fine performance mesh design is featured on all sides of the chassis, combining high airflow with good dust filtration. The bottom features a high-quality dust filter with an immense intake area that provides the best cooling performance to the GPU. A total of twelve 120mm fan positions make sure the NV7 is ready for any challenge.

Highlights

Form Factor: ATX Full Tower
Material: Steel Chassis / Tempered Glass
Side Window: Yes, Front and Side Tempered Glass
Motherboard Support: Micro ATX / ATX / Mini ITX / SSI-CEB/ E-ATX (up to 277mm wide with LED Cover)
Expansion Slots: 8
Front Ports: 2 x USB 3.0, USB-C Gen2, Microphone/Headphone Combo, Power Button, D-RGB Mode, D-RGB Color, D-RGB Speed, D-RGB Channel
3.5" Drive Bays: 2 (1 x if all SSD positions are used)
2.5" Drive Bays: 6 (4 x if both HDD positions are used)
Fan Options: Side - 4 x 120mm, Top - 3 x 120mm, Rear - 2 x 120mm, Bottom - 3 x 120mm; 3 x 140mm
Radiator: Bottom - Up to 360mm; Up to 280 (140mm radiator), Rear - Up to 240mm, Side - Up to 360mm, Top - Up to 360mm
Max GPU Length: 450 mm
Max CPU Cooler Height: 185 mm
Max PSU Length: 255 mm
Warranty: 5 Years limited
