FRAME 4000D RS Modular Mid-Tower
Highlights
The revolutionary FRAME Modular Case System redefines customization. Want to upgrade the motherboard tray to billet aluminum? Want to replace your front I/O panel for more USB ports? Now you can.
This case evolves with your needs, offering near limitless options for upgrades and changes.
This steel multi-point mounting system provides unmatched flexibility for front and roof fan configurations. Easily slide the rail to mount fans up to 200mm (140mm in the roof) exactly where you need them, ensuring targeted airflow without limitations of fixed mounting points.
Engineered for maximum airflow and minimal resistance, the new 3D Y-pattern steel front panel ensures a smooth, unobstructed path for cool air, enhancing overall cooling.
Boost your cooling with three dedicated mounting locations for 360mm radiators – front, roof, and side. You can mount up to 10x 120mm fans simultaneously, ensuring continuous cool air intake and efficient hot air exhaust.
THREE RS120 FANS INCLUDED -
RS120 PWM fans feature daisy-chainable connections for easy setup. Their magnetic dome bearings minimize friction, delivering a perfect combination of high airflow and quiet operation.
Ensure your build has excellent airflow with careful cable routing and support for the latest motherboards and graphics cards.
Fully compatible with reverse-connector motherboards from Asus, MSI, and Gigabyte, allowing for unobstructed airflow and a super-clean build.
Every CORSAIR FRAME 4000D includes a GPU Anti-sag Stabilization Arm to keep your GPU steady, so you never have to worry about damaging your PCIe slot.
Keep unused and overly long cables out of sight with the cable shroud for a clean and organized interior.
Customize your cooling setup with room for up to 12x 120mm fans, plus versatile radiator mounting options including up to dual 360mm radiators.
The FRAME 4000D has more than enough space to accommodate and cool your most ambitious build.
Puts your connections within easy reach, including a USB 3.2 Gen 2 Type-C Port, 2x USB 3.2 Gen 1 Type-A ports, and a combination audio/microphone jack.
Specifications
- Case Size - Mid-Tower
- Dimensions H/L/W- 486mm, 490mm, 239mm
- Color - Black
- Reverse Connector Motherboard Support - Yes
- Material - Steel, Tempered Glass, 3D-Y Airflow Steel, Plastic
- Case Power Supply - ATX
- Motherboard Support - Mini-ITX, Micro-ATX, ATX, E-ATX (305mm x 277mm)
- Expansion Slots - 7 Horizontal or 3 Vertical
- Vertical Mount Support - Supported (Riser Card Sold Separately)
- Case Front IO - (1x) USB 3.2 Gen 2 Type-C, (2x) USB 3.2 Gen 1 Type-A, (1x) Audio in/out
- Internal 2.5" Drive Bays - 4
- Internal 3.5" Drive Bays - 2
- Included Fans - 3 x RS120 PWM fans
- Fan Support - Top - 3x 120mm, 2x 140mm
- Fan Support - Front - 3x 120mm, 2x 140mm, 2x 200mm
- Fan Support - Bottom - 2x 120mm
- Fan Support - Side - 3x 120mm; 2x 140mm
- Fan Support - Rear - 1x 120mm, 1x 140mm
- Compatible Liquid Coolers - H60, H100, H115, H150, NAUTILUS, TITAN
- Radiator Compatibility - 120mm, 140mm, 240mm, 280mm, 360mm
- Radiator Support - Top - 360mm, 280mm, 240mm
- Radiator Support - Front - 360mm, 280mm, 240mm
- Radiator Support - Bottom - None
- Radiator Support - Side - 360mm, 280mm, 240mm
- Radiator Support - Rear - 140mm, 120mm
- Maximum GPU Length - 430mm
- Maximum CPU Cooler Height - 170mm
- Maximum PSU Length - 220mm
- Dust Filtration - Yes
- Cable Routing Space - 37mm
- Warranty - 2 Years
