ZenWiFi AX Mini XD4 (W-3-PK)

The ZenWiFi AX Mini system consists of one ASUS AX1800 WiFi 6 router and two extending node, featuring unique technologies that give you superfast, reliable and secure WiFi connections — inside or outside your home!

Uniquely, ZenWiFi lets you choose how you name your WiFi networks: a single name for everything, or separate names for each frequency band. The choice is yours!

AiProtection Classic with Parental Controls is free for life. It gives you total peace of mind, and you can keep an eye on everything that's happening on your network via the mobile app.

ZenWiFi AX Mini works perfectly with smart-home services — including Alexa skills and IFTTT — and is available in charcoal or white to suit your décor.

Highlights

• AX technology: Yes
• Product Segment: AX1800 ultimate AX performance : 1201 Mbps+ 574 Mbps
• Network Standard: IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, WiFi 4 (802.11n), WiFi 5 (802.11ac), WiFi 6 (802.11ax), IPv4, IPv6
• Data Rate: 802.11a : up to 54 Mbps, 802.11b : up to 11 Mbps, 802.11g : up to 54 Mbps, WiFi 4 (802.11n) : up to 300 Mbps, WiFi 5 (802.11ac) : up to 867 Mbps, WiFi 6 (802.11ax) (2.4GHz) : up to 574 Mbps, WiFi 6 (802.11ax) (5GHz) : up to 1201 Mbps
• Antenna: Internal dual-band antenna x 2
• Transmit/Receive: MIMO technology, 2.4GHz 2x2, 5GHz 2x2
• Memory: 256 MB Flash, 256 MB RAM
• Boosts speed: MIMO technology
• Operating Frequency: 2.4 G Hz / 5 GHz
• Ports: RJ45 for Gigabits BaseT for WAN/LAN x 1, RJ45 for Gigabits BaseT for LAN x1
• Button: WPS Button, Reset Button
• LED Indicator: Power x 1
• Power Supply: "AC Input : 110V~240V(50~60Hz) - DC Output : 12 V with max. 1.5 A current"
• AiMesh: AiMesh, Primary AiMesh router, AiMesh node
• Router APP: ASUS Router APP
• Alexa: Support Alexa skill
• IFTTT: Support IFTTT
• AiProtection: AiProtection Classic, Malicious site blocking, Infected Device Prevention and Blocking
• Parental Control: Parental Control, Parental Control Customized Internet schedule
• Traffic Control: Bandwidth Monitor, Bandwidth limiter, Traditional QoS, Maximum Traditional QoS rule : 32, Real-time traffic monitor, Wired Traffic Monitor, Wireless Traffic Monitor
• Wireless: IPv6, Wi-Fi Encryption : WPA3-Personal, WPA/WPA2/WPA3-Personal, WPA/WPA2-Enterprise, WPS support, UTF-8 SSID, Guest Network, Maximum Guest Network rule : 9, Guest Network Connection time limit, WPS
• WAN: Internet connection Type : PPPoE, PPTP, L2TP, Automatic IP, Static IP, Android tethering, Port forwarding, Port triggering, DMZ, DDNS, NAT Passthrough : Automatic IP, Static IP, PPPoE(MPPE supported), PPTP, L2TP, Let's Encrypt
• LAN: DHCP Server, IGMP snooping, IPTV, Manually assign IP address, Maximum manually assign IP address rule : 64
• VPN: VPN Client L2TP, VPN Client OVPN, VPN Client PPTP, VPN Server IPSec, VPN Server OVPN, VPN Server PPTP
• Administration: Operating system : ASUSWRT, Free OS upgrade, Firewall, Maximum Firewall keyword filter : 64, Maximum Firewall network service filter : 32, Maximum Firewall URL filter : 64, Wake on LAN (WOL), SSH, Configuration backup and restore, Diagnosis tools, Feedback system, System log
• Package content: 3-pack router x 1+node x 2, Router (XD4R), RJ45 Ethernet cable, Power adapter, Quick start guide, Warranty Card, Router (XD4R), Node (XD4N), RJ45 Ethernet cable, Power adapter, Quick start guide, Warranty Card
