ASUS ExpertWiFi EBA63

Seamless and Extendable Connections — Enjoy uninterrupted roaming with WiFi 6 speeds of up to 3000 Mbps, support for up to 100 active devices and easy scalability to meet the evolving needs of your business network.

Secure and Segmented Networking – Easy WiFi network settings via Self-defined Networks, and enhanced business security with VLAN support, offering up to five SSIDs for device segregation and prioritization in diverse business scenarios.

Flexible Deployment with PoE — Support for both Power over Ethernet (PoE) connection and AC adapters, providing versatile options for installation.

Accommodate to Any Space — Supports ceiling and wall mounting to fit into various business environments with more flexibility.

Built for Safety and Reliability — Compliant with IEC 60601-1-2 standards, and with the top half of the device made of materials that meet the UL94 5VB plastics flammability standard*, the EBA63 ensures a stable and reliable connection.

The ASUS ExpertWiFi EBA63 is a Power over Ethernet (PoE) solution that provides fast, seamless and secure networking, with rich features tailored for small-to-midsized businesses. With its easy scalability, it can effortlessly adapt to your business network needs.

Highlights

Model: ASUS ExpertWiFi EBA63
Network Standard: IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, WiFi 4 (802.11n), WiFi 5 (802.11ac), WiFi 6 (802.11ax), IPv4, IPv6
Product Segment: AX3000 ultimate AX performance : 2402 Mbps+ 574 Mbps
Data Rate: 802.11a : up to 54 Mbps, 802.11b : up to 11 Mbps, 802.11g : up to 54 Mbps, WiFi 4 (802.11n) : up to 300 Mbps, WiFi 5 (802.11ac) : up to 1734 Mbps, WiFi 6 (802.11ax) (2.4GHz) : up to 574 Mbps, WiFi 6 (802.11ax) (5GHz) : up to 2402 Mbps
Antenna: Internal antenna x 4
Transmit/Receive: 2.4GHz 2x2, 5GHz 2x2
Processor: 1.7 GHz quad-core processor
Memory: 256 MB Flash, 512 MB RAM
Boosts Speed: OFDMA (Orthogonal Frequency Division Multiple Access), Beamforming: standard-based and universal, 1024-QAM high data rate, 20/40/80/160 MHz bandwidth
Operating Frequency: 2.4 GHz, 5 GHz
Operating Mode: AiMesh Node Mode, Access Point Mode
I/O Ports: 10/100/1000 Gigabit Ethernet Port (support PoE) x 1
Buttons: Reset Button
LED Indicator: Power x 2
Power Supply: 802.3af PoE, 12 V with max. 1.5 A current DC (power adapter included)
Power Consumption: 10.0W
Mounting: Wall Mount, Ceiling Mount
AiMesh: AiMesh, AiMesh Node
Device Access Control: Time Scheduling, Reward, Customized Internet Schedule • Maximum Device Access Control Profile :12 • Maximum Device Access Control Content Filter Rule :12
Dashboard: Dashboard
Self-Defined Network: "You can create additional networks for different purposes, these networks are separate from the main network domain, to provide enhanced security, and create comprehensive network environment with customized settings." Self-Defined Network Type, • Employee • Guest Network • Scheduled Network • Maximum Self-Defined Network Rule :16, VLAN, WiFi Scheduling: One Time Access, WiFi Scheduling: Weekly Schedule, WiFi share: QR code, PDF file, AP isolate
Security: WPA/WPA2/WPA3-Personal, WPA/WPA2-Enterprise, WPS, SSH
Traffic Control: Real-time Traffic Monitor • Wired Traffic Monitor • Wireless Traffic Monitor
Wireless: UTF-8 SSID, WiFi MAC Address Filter • Maximum MAC Filters : 64, Wireless Scheduler
User Interface: WEB: ASUSWRT, APP: ASUS ExpertWiFi APP
Administration: Configuration Backup and Restore, Diagnosis Tools, Feedback System, System Log, New Device Connect Notification, Login Captcha, Connection Diagnosis, Auto Firmware Update
Package Content: ExpertWiFi EBA63, RJ-45 cable, Power adapter, Warranty card, Quick start guide, Wall-mount kit
